The CL-SFM35EX is a slimline physical request to exit device that is able to be surface mounted due to its enclosed metal housing.
The exit button is only 35mm wide. This allows it to fit on 40mm or wider metal door frames.
It features three wires for relay control (NC/COM/NO). After being wired into a new or existing access control system, it can be used to open a Mag Lock, Electric Strike or V-Lock.
Weight - 100g
Dimensions - 115mm x 40mm
Wire Colours
| White | Relay Normally Closed |
| Yellow | Relay Common |
| Green | Relay Normally Open |
